For Coating and Paints
NYASTA ORANGE 36L
Technical Data Sheet of Pigment Orange 36 for Coatings and Paints
Revision No.: 1
Revision Date: 08 / 2017
| Color Index Name | Pigment Orange 36 |
| Color Index Number (C.I No.) | 11780 |
| Chemical Type / Class | Benzimidazolone Pigment |
| CAS No | 12236-62-3 |
| EINECS Number | 235-462-4 |
| Molecular Formula | C17H13CIN6O5 |
| Molecular Weight [g/mol] | 416.778 |
| Appearance | Orange Powder |
| Density [gr /cm3] | 1.55 - 1.70 |
| Bulk Volume [ltr /kg] | 2.1 - 3.4 |
| Specific Surface [m2/ gr] | 19 - 32 |
| Oil Absorption [ml/100gr] | 50 - 70 |
| PH of 10% Extract | 5.5 - 7.5 |
| Moisture Content | Max. 1% |
| Acid | 5 |
| Alkali | 5 |
| Water | 5 |
| Butanol | 4.5 |
| Butyl Acetate | 4.5 |
| Xylene | 4.5 |
| MEK | 4 |
| White Spirits | 5 |
| Full Shade | 8 |
| 1:1TiO2 | 7 |
| Decorative Water based paints | Recommended |
| Decorative Solvent based paints | Recommended |
| Industrial Paints | Recommended |
| Powder Coatings | Recommended |
| Automotive Coating | Recommended |
| Coil coating | Recommended |
| Textile Printings | Recommended |
| Printings Inks | Recommended |
| Waterborne Paints | Recommended |
| Air Drying Alkyds | Recommended |
| Stoving Enamels | Recommended |
| Acid curing epoxies | Recommended |
| Isocyanate Cured System | Recommended |
| Full Shade | 5 |
| 1:1TiO2 | 4 |
| 15 - 20 KGS Paper Bag |
| Also Packaging avilable as per your Convenience |
| Germany BFR recom. IX | Compliant |
| AP 89/1 | Compliant |
| USA (FDA) 21 CFR 178.3297 | Compliant |
| Toys Europe EN 71-03 : 2013 | Compliant |
| Toy USA ASTM F 963-03 | Compliant |
| CONEG, EC 94/62 | Compliant |
| ROHS, 2002/95/E, 2005/618/EC | Compliant |
| End of Life Vehicles, 2000/53/EC, 2002/525/EC | Compliant |
| Opaque Orange Pigment with high tinting strength excellent light fastness and weathering properties |
| Novoperm Orange HL/ HL 70 EDW VP 3965/ HL 70-NF. |
| Hostatint Orange A-HLD 100/ HLD 530 VP 5387 / HLD 500. |
| DCC Oraqnge 7136 |
| Vijay Orange 60936 |
| All ingredients are listed in the following national chemicals Inventories: |
| EINECS [Europe], |
| TSCA [USA], |
| DSL (Canada), |
| AICS [Australia], |
| NZIoC [New Zealand], |
| MITI [Japan], |
| ECL [Korea], |
| IECSC [China], |
| PICCS [Philippines] |
Note: Information given in this technical data sheet is based on current knowledge and our laboratory evaluation; it is presented as per our opinion without any guarantee. Buyers must carry out their own tests and experiments to determine the suitability and completeness of our products for their use and application.
